دیتاشیت SBS822-TL-W
مشخصات دیتاشیت
| نام دیتاشیت |
SBS822
|
| حجم فایل |
201.528
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi SBS822-TL-W
-
Diode Configuration:
2 Independent
-
Reverse Voltage (Vr):
20V
-
Forward Voltage (Vf@If):
460mV@1A
-
Reverse Leakage Current (Ir):
110uA@10V
-
Average Rectified Current (Io):
1A
-
Package:
SOT-353
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
20V
-
Current - Average Rectified (Io) (per Diode):
1A
-
Voltage - Forward (Vf) (Max) @ If:
460mV @ 1A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
10ns
-
Current - Reverse Leakage @ Vr:
110µA @ 10V
-
Operating Temperature - Junction:
-55°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
6-SMD (5 Leads), Flat Lead
-
Supplier Device Package:
5-MCPH
-
Base Part Number:
SBS822
-
detail:
Diode Array 2 Independent Schottky 20V 1A Surface Mount 6-SMD (5 Leads), Flat Lead
