SMF15CT1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SMF15CT1G |
|---|---|
| حجم فایل | 31.44 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت SMF15CT1G |
دانلود دیتاشیت |
|---|
سایر مستندات
SMF05C, 12C, 15C, 24C 5 pages
SMF15CT1G 6 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: onsemi SMF15CT1G
- Clamping Voltage@Ipp: 29V
- Operating Temperature: -40°C~+125°C@(Tj)
- Breakdown Voltage (VBR): 17V
- Peak Pulse Power(Ppp)@8/20us: 100W
- Junction Capacitance(Cj)@1MHz: 33pF@1MHz
- Reverse Stand-Off Voltage (Vrwm): 15V
- Package: SOT-323-6
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 5
- Voltage - Reverse Standoff (Typ): 15V (Max)
- Voltage - Breakdown (Min): 17V
- Voltage - Clamping (Max) @ Ipp: 29V
- Current - Peak Pulse (10/1000µs): 5A (8/20µs)
- Power - Peak Pulse: 100W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 33pF @ 1MHz
- Mounting Type: Surface Mount
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Supplier Device Package: SC-88/SC70-6/SOT-363
- Base Part Number: SMF
- detail: 29V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount SC-88/SC70-6/SOT-363
