NCV8163ASN180T1G دیتاشیت

NCV8163ASN180T1G

مشخصات دیتاشیت

نام دیتاشیت NCV8163ASN180T1G
حجم فایل 82.652 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

مشاهده دیتاشیت NCV8163ASN180T1G

دانلود دیتاشیت

سایر مستندات

NCV8163 17 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV8163ASN180T1G
  • Output Current: 250mA
  • Output Voltage: 1.8V
  • Dropout Voltage: 0.28V@(250mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Quiescent Current (Ground Current): 20uA
  • Package: SOT-23-5
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 1.8V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.28V @ 250mA
  • Current - Output: 250mA
  • Current - Quiescent (Iq): 20µA
  • PSRR: 92dB ~ 60dB (100Hz ~ 100kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: 5-TSOP
  • Base Part Number: NCV8163
  • detail: Linear Voltage Regulator IC 1 Output 250mA 5-TSOP
