NTLUS030N03CTAG دیتاشیت

NTLUS030N03CTAG

مشخصات دیتاشیت

نام دیتاشیت NTLUS030N03CTAG
حجم فایل 91.323 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت NTLUS030N03CTAG

دانلود دیتاشیت

سایر مستندات

NTLUS030N03C 7 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi NTLUS030N03CTAG
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 640mW
  • Total Gate Charge (Qg@Vgs): 8nC@10V
  • Drain Source Voltage (Vdss): 30V
  • Input Capacitance (Ciss@Vds): 400pF@15V
  • Continuous Drain Current (Id): 4.5A
  • Gate Threshold Voltage (Vgs(th)@Id): 2.2V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 18mΩ@6A,10V
  • Package: UDFN-6
  • Manufacturer: onsemi
  • Series: µCool™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 4.5A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 18mOhm @ 6A, 10V
  • Vgs(th) (Max) @ Id: 2.2V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 8nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 400pF @ 15V
  • FET Feature: -
  • Power Dissipation (Max): 640mW (Ta)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-UDFN (1.6x1.6)
  • Package / Case: 6-PowerUFDFN
  • Base Part Number: NTLUS03
  • detail: N-Channel 30V 4.5A (Ta) 640mW (Ta) Surface Mount 6-UDFN (1.6x1.6)
