NCP571MN12TBG دیتاشیت

NCP571MN12TBG

مشخصات دیتاشیت

نام دیتاشیت NCP571MN12TBG
حجم فایل 77.595 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

مشاهده دیتاشیت NCP571MN12TBG

دانلود دیتاشیت

سایر مستندات

NCP571,NCV571 11 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCP571MN12TBG
  • Output Current: 150mA
  • Output Voltage: 1.2V
  • Dropout Voltage: 0.45V@(10mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 12V
  • Operating Temperature: -40°C~+85°C
  • Quiescent Current (Ground Current): 1uA
  • Package: DFN-6(2x2.2)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 12V
  • Voltage - Output (Min/Fixed): 1.2V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.45V @ 10mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 1µA
  • Current - Supply (Max): 8µA
  • PSRR: -
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: 6-VDFN Exposed Pad
  • Supplier Device Package: 6-DFN (2x2.2)
  • Base Part Number: NCP571
  • detail: Linear Voltage Regulator IC 1 Output 150mA 6-DFN (2x2.2)
