دیتاشیت NCV78M08BDTRKG
مشخصات دیتاشیت
| نام دیتاشیت | MC78M00(A), NCV78M00 Series |
|---|---|
| حجم فایل | 141.284 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت MC78M00(A), NCV78M00 Series |
MC78M00(A), NCV78M00 Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCV78M08BDTRKG
- Output Current: 700mA
- Output Voltage: 8V
- Dropout Voltage: 2V@(350mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: -40°C~+125°C@(Tj)
- Power Supply Rejection Ratio (PSRR): 80dB@(120Hz)
- Package: DPAK-3
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 35V
- Voltage - Output (Min/Fixed): 8V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 2V @ 350mA (Typ)
- Current - Output: 700mA
- PSRR: 80dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: NCV78
- detail: Linear Voltage Regulator IC 1 Output 700mA DPAK
