NCS2200SQ2T2G دیتاشیت

NCS2200SQ2T2G

مشخصات دیتاشیت

نام دیتاشیت NCS2200SQ2T2G
حجم فایل 84.165 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت NCS2200SQ2T2G

دانلود دیتاشیت

سایر مستندات

NCS2200,02(A) 18 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: onsemi NCS2200SQ2T2G
  • Output Type: Push Pull
  • Supply Voltage: 0.85V~6V
  • Number of Elements: -
  • Operating Temperature: -40°C~+105°C
  • Input Bias Current (Ib): 1pA
  • Input Offset Voltage (Vos): 5mV
  • Input Hysteresis Voltage (Vhys): 20mV
  • Common Mode Rejection Ratio (CMRR): 100dB
  • Package: TSSOP-5
  • Manufacturer: onsemi
  • Series: NCS2200
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Type: General Purpose
  • Voltage - Supply, Single/Dual (±): 0.85V ~ 6V
  • Voltage - Input Offset (Max): 5mV @ 6V
  • Current - Input Bias (Max): 1pA @ 6V
  • Current - Output (Typ): -
  • Current - Quiescent (Max): 17µA
  • CMRR, PSRR (Typ): 70dB CMRR, 80dB PSRR
  • Propagation Delay (Max): 1.1µs
  • Hysteresis: 20mV
  • Package / Case: 5-TSSOP, SC-70-5, SOT-353
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-88A (SC-70-5/SOT-353)
  • Base Part Number: NCS2200
  • detail: Comparator General Purpose Complementary, Rail-to-Rail SC-88A (SC-70-5/SOT-353)
