دیتاشیت LM385D-1.2R2G
مشخصات دیتاشیت
| نام دیتاشیت |
LM285, LM385B
|
| حجم فایل |
96.982
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Voltage References
-
Datasheet:
onsemi LM385D-1.2R2G
-
Tolerance:
-2.4%~+2.01%
-
Output Type:
Fixed
-
Input Voltage:
-
-
Output Current:
20mA
-
Output Voltage:
1.235V
-
Reference Type:
parallel connection
-
Supply Current:
-
-
Noise - 10Hz to 10kHz:
60uVrms
-
Operating Temperature:
0°C~+70°C@(Ta)
-
Noise - 1/10Hz to 10Hz:
-
-
Temperature Coefficient:
80ppm/°C
-
Package:
SOP-8
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Voltage - Output (Min/Fixed):
1.235V
-
Current - Output:
20mA
-
Noise - 0.1Hz to 10Hz:
-
-
Voltage - Input:
-
-
Current - Supply:
-
-
Current - Cathode:
20µA
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
LM385
-
detail:
Shunt Voltage Reference IC -2.4%, +2.01% 8-SOIC
