دیتاشیت MC79M08BDTRKG
مشخصات دیتاشیت
| نام دیتاشیت |
MC79M00 Series
|
| حجم فایل |
139.284
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi MC79M08BDTRKG
-
Output Current:
500mA
-
Output Voltage:
8V
-
Dropout Voltage:
1.1V@(500mA)
-
Output Polarity:
Negative
-
Number of Outputs:
1
-
Maximum Input Voltage:
35V
-
Operating Temperature:
-40°C~+125°C
-
Power Supply Rejection Ratio (PSRR):
63dB@(120Hz)
-
Package:
TO-252
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Output Configuration:
Negative
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
-35V
-
Voltage - Output (Min/Fixed):
-8V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
1.1V @ 500mA (Typ)
-
Current - Output:
500mA
-
PSRR:
63dB (120Hz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
DPAK
-
Base Part Number:
MC79M08
-
detail:
Linear Voltage Regulator IC 1 Output 500mA DPAK
