FFD08S60S-F085 دیتاشیت

FFD08S60S-F085

مشخصات دیتاشیت

نام دیتاشیت FFD08S60S-F085
حجم فایل 87.101 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

مشاهده دیتاشیت FFD08S60S-F085

دانلود دیتاشیت

سایر مستندات

FFD08S60S_F085 4 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - General Purpose
  • Datasheet: onsemi FFD08S60S-F085
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 800V
  • Forward Voltage (Vf@If): 2.1V@8A
  • Reverse Leakage Current: 100uA@600V
  • Average Rectified Current (Io): 8A
  • Package: DPAK-3
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101, STEALTH™ II
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 8A
  • Voltage - Forward (Vf) (Max) @ If: 2.6V @ 8A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 30ns
  • Current - Reverse Leakage @ Vr: 100µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: TO-252
  • Operating Temperature - Junction: -65°C ~ 150°C
  • Base Part Number: FFD08
  • detail: Diode Standard 600V 8A Surface Mount TO-252
