NCP13992AADR2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP13992AADR2G
|
|
حجم فایل
|
92.056
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
30
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Half-Bridge
-
Datasheet:
onsemi NCP13992AADR2G
-
Duty Cycle:
50%
-
Supply Voltage:
20V
-
Output Isolation:
Isolation
-
Switching Frequency:
20kHz~750kHz
-
Operating Temperature:
-50°C~+150°C@(Tj)
-
Package:
SOP-16
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Internal Switch(s):
No
-
Voltage - Breakdown:
-
-
Voltage - Start Up:
9V
-
Voltage - Supply (Vcc/Vdd):
20V
-
Frequency - Switching:
20kHz ~ 750kHz
-
Fault Protection:
Current Limiting, Over Load, Over Power, Over Temperature, Over Voltage, Short Circuit
-
Control Features:
EN, Frequency Control, Soft Start, Sync
-
Package / Case:
16-SOIC (0.154", 3.90mm Width), 14 Leads
-
Supplier Device Package:
16-SOIC
-
Mounting Type:
Surface Mount
-
Base Part Number:
NCP13992
-
detail:
Converter Offline Half-Bridge Topology 20kHz ~ 750kHz 16-SOIC
