NTLUS3A18PZTBG دیتاشیت

NTLUS3A18PZTBG

مشخصات دیتاشیت

نام دیتاشیت NTLUS3A18PZTBG
حجم فایل 93.658 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

مشاهده دیتاشیت NTLUS3A18PZTBG

دانلود دیتاشیت

سایر مستندات

NTLUS3A18PZ 6 pages

مشخصات فنی

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi NTLUS3A18PZTBG
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 700mW
  • Total Gate Charge (Qg@Vgs): 28nC@4.5V
  • Input Capacitance (Ciss@Vds): 2240pF@15V
  • Continuous Drain Current (Id): 5.1A
  • Gate Threshold Voltage (Vgs(th)@Id): 1V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 18mΩ@7A,4.5V
  • Package: UDFN-6
  • Manufacturer: onsemi
  • Series: µCool™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 20V
  • Current - Continuous Drain (Id) @ 25°C: 5.1A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 1.5V, 4.5V
  • Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 4.5V
  • Vgs(th) (Max) @ Id: 1V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 28nC @ 4.5V
  • Vgs (Max): ±8V
  • Input Capacitance (Ciss) (Max) @ Vds: 2240pF @ 15V
  • FET Feature: -
  • Power Dissipation (Max): 700mW (Ta)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-UDFN (2x2)
  • Package / Case: 6-UDFN Exposed Pad
  • Base Part Number: NTLUS3A
  • detail: P-Channel 20V 5.1A (Ta) 700mW (Ta) Surface Mount 6-UDFN (2x2)
