دیتاشیت SB10-05P-TD-E

SB10-05P

مشخصات دیتاشیت

نام دیتاشیت SB10-05P
حجم فایل 331.459 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت SB10-05P

SB10-05P Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi SB10-05P-TD-E
  • Reverse Voltage (Vr): 50V
  • Forward Voltage (Vf@If): 550mV@1A
  • Reverse Leakage Current (Ir): 80uA@25V
  • Average Rectified Current (Io): 1A
  • Package: SOT-89
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 50V
  • Current - Average Rectified (Io): 1A
  • Voltage - Forward (Vf) (Max) @ If: 550mV @ 1A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 10ns
  • Current - Reverse Leakage @ Vr: 80µA @ 25V
  • Capacitance @ Vr, F: 52pF @ 10V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: TO-243AA
  • Supplier Device Package: SOT-89/PCP-1
  • Operating Temperature - Junction: -55°C ~ 125°C
  • Base Part Number: SB10
  • detail: Diode Schottky 50V 1A Surface Mount SOT-89/PCP-1
