دیتاشیت NSR1030QMUTWG
مشخصات دیتاشیت
| نام دیتاشیت |
NSR1030QMUTWG
|
| حجم فایل |
70.749
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Bridge Rectifiers
-
Datasheet:
onsemi NSR1030QMUTWG
-
Reverse Voltage (Vr):
30V
-
Operating Temperature:
+125°C@(Tj)
-
Forward Voltage (Vf@If):
600mV@1A
-
Peak Forward Surge Current:
12A
-
Reverse Leakage Current (Ir):
20uA@30V
-
Average Rectified Current (Io):
1A
-
Package:
UDFN-4(3x3)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Single Phase
-
Technology:
Schottky
-
Voltage - Peak Reverse (Max):
30V
-
Current - Average Rectified (Io):
1A
-
Voltage - Forward (Vf) (Max) @ If:
600mV @ 1A
-
Current - Reverse Leakage @ Vr:
20µA @ 30V
-
Mounting Type:
Surface Mount
-
Package / Case:
4-UDFN Exposed Pad
-
Supplier Device Package:
4-UDFN (3x3)
-
Base Part Number:
NSR103
-
detail:
Bridge Rectifier Single Phase Schottky 30V Surface Mount 4-UDFN (3x3)
