FDME910PZT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
FDME910PZT
|
|
حجم فایل
|
435.591
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
PowerTrench®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
P-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
8A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
1.8V, 4.5V
-
Rds On (Max) @ Id, Vgs:
24mOhm @ 8A, 4.5V
-
Vgs(th) (Max) @ Id:
1.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
21nC @ 4.5V
-
Vgs (Max):
±8V
-
Input Capacitance (Ciss) (Max) @ Vds:
2110pF @ 10V
-
FET Feature:
-
-
Power Dissipation (Max):
2.1W (Ta)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
MicroFet 1.6x1.6 Thin
-
Package / Case:
6-PowerUFDFN
-
Base Part Number:
FDME91
-
detail:
P-Channel 20V 8A (Ta) 2.1W (Ta) Surface Mount MicroFet 1.6x1.6 Thin
