NCV8730ASNADJT1G دیتاشیت

NCV8730ASNADJT1G

مشخصات دیتاشیت

نام دیتاشیت NCV8730ASNADJT1G
حجم فایل 82.673 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

مشاهده دیتاشیت NCV8730ASNADJT1G

دانلود دیتاشیت

سایر مستندات

NCV8730 30 pages

مشخصات فنی

  • RoHS: true
  • Feature: enable
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV8730ASNADJT1G
  • Output Type: Adjustable
  • Output Current: 150mA
  • Output Voltage: 1.2V~24V
  • Dropout Voltage: 480mV@(150mA)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 38V
  • Quiescent Current (Ground Current): 3uA
  • Power Supply Rejection Ratio (PSRR): 80dB@(10Hz),42dB@(100kHz)
  • Package: TSOP-5-1.5mm
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 38V
  • Voltage - Output (Min/Fixed): 1.2V
  • Voltage - Output (Max): 24V
  • Voltage Dropout (Max): 0.48V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 3µA
  • PSRR: 80dB ~ 42dB (10Hz ~ 100kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: 5-TSOP
  • detail: Linear Voltage Regulator IC 1 Output 150mA 5-TSOP
