NCP705MT28TCG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP705
|
|
حجم فایل
|
2009.82
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
20
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
2.8V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.35V @ 500mA
-
Current - Output:
500mA
-
Current - Quiescent (Iq):
25µA
-
PSRR:
73dB ~ 56dB (100Hz ~ 10kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Soft Start, Under Voltage Lockout (UVLO)
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
6-WDFN Exposed Pad
-
Supplier Device Package:
6-WDFN (2x2)
-
Base Part Number:
NCP705
-
detail:
Linear Voltage Regulator IC 1 Output 500mA 6-WDFN (2x2)
