- دیتاشیت NJVMJD253T4G-VF01
NJVMJD253T4G-VF01 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NJVMJD253T4G-VF01 |
|---|---|
| حجم فایل | 86.203 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت NJVMJD253T4G-VF01 |
دانلود دیتاشیت |
|---|
سایر مستندات
MJD243,253 8 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Audio Power OpAmps
- Datasheet: onsemi NJVMJD253T4G-VF01
- Package: DPAK-3
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Transistor Type: PNP
- Current - Collector (Ic) (Max): 4A
- Voltage - Collector Emitter Breakdown (Max): 100V
- Vce Saturation (Max) @ Ib, Ic: 300mV @ 50mA, 500mA
- Current - Collector Cutoff (Max): -
- DC Current Gain (hFE) (Min) @ Ic, Vce: 40 @ 200mA, 1V
- Power - Max: 12.5W
- Frequency - Transition: 40MHz
- Operating Temperature: -65°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: MJD25
- detail: Bipolar (BJT) Transistor PNP 100V 4A 40MHz 12.5W Surface Mount DPAK
