FSA1153UCX دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FSA1153UCX	دانلود دیتاشیت

FSA1153 11 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: onsemi FSA1153UCX
Turn-on time: 80us
Turn-off time: 400ns
Supply Voltage: 2.7V~5.5V
Switch Circuit: 双刀三掷(DP3T)
Number of Channels: 1
On-State Resistance (Max): 2Ω
Package: WLCSP-12
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: -
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 200mOhm (Max)
Voltage - Supply, Single (V+): 2.7V ~ 5.5V
Voltage - Supply, Dual (V±): -
Switch Time (Ton, Toff) (Max): 80µs, 400ns (Typ)
-3db Bandwidth: 500MHz
Charge Injection: -
Channel Capacitance (CS(off), CD(off)): 2.5pF, 7pF
Current - Leakage (IS(off)) (Max): 100nA
Crosstalk: -120dB @ 1kHz
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 12-UFBGA, WLCSP
Supplier Device Package: 12-WLCSP (1.41x1.575)
Base Part Number: FSA11
detail: 1 Circuit IC Switch 2Ohm 12-WLCSP (1.41x1.575)
