- Datasheet FPF2411BUCX-F130
FPF2411BUCX-F130 Datasheet
Datasheet specifications
| Datasheet's name | FPF2411BUCX-F130 |
|---|---|
| File size | 50.018 KB |
| File type | |
| Number of pages | 14 |
Download Datasheet FPF2411BUCX-F130 |
Download Datasheet |
|---|
Other documentations
FPF2411 13 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Power Distribution Switches
- Datasheet: onsemi FPF2411BUCX-F130
- Input Voltage: 2.3V~5.5V
- Output Current: 6A
- Number of Outputs: 1
- Resistor On-State: 10mΩ
- Package: WLCSP-12
- Manufacturer: onsemi
- Series: IntelliMAX™
- Packaging: Cut Tape (CT)
- Part Status: Active
- Switch Type: General Purpose
- Ratio - Input:Output: 1:1
- Output Configuration: High Side
- Output Type: P-Channel
- Interface: On/Off
- Voltage - Load: 2.3V ~ 5.5V
- Voltage - Supply (Vcc/Vdd): Not Required
- Current - Output (Max): 6A
- Rds On (Typ): 10mOhm
- Input Type: Non-Inverting
- Features: Slew Rate Controlled
- Fault Protection: Reverse Current
- Operating Temperature: -
- Mounting Type: Surface Mount
- Supplier Device Package: 12-WLCSP (1.29x1.83)
- Package / Case: 12-UFBGA, WLCSP
- Base Part Number: FPF2
- detail: Power Switch/Driver 1:1 P-Channel 6A 12-WLCSP (1.29x1.83)
