NCV4276BDT33RKG دیتاشیت

NCV4276BDT33RKG

مشخصات دیتاشیت

نام دیتاشیت NCV4276BDT33RKG
حجم فایل 68.138 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت NCV4276BDT33RKG

دانلود دیتاشیت

سایر مستندات

NCV4276B 18 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV4276BDT33RKG
  • Package: TO-263-6
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Not For New Designs
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 45V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): -
  • Current - Output: 400mA
  • Current - Quiescent (Iq): 200µA
  • Current - Supply (Max): 35mA
  • PSRR: 70dB (100Hz)
  • Control Features: Enable
  • Protection Features: Over Temperature, Reverse Polarity, Short Circuit
  • Operating Temperature: -40°C ~ 150°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-5, DPak (4 Leads + Tab), TO-252AD
  • Supplier Device Package: DPAK-5
  • Base Part Number: NCV4276
  • detail: Linear Voltage Regulator IC 1 Output 400mA DPAK-5
