NCS2202SQ1T2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCS2202SQ1T2G
|
|
حجم فایل
|
79.95
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
18
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
onsemi NCS2202SQ1T2G
-
Output Type:
Open Drain;轨到轨
-
Supply Voltage:
0.85V~6V
-
Number of Elements:
-
-
Operating Temperature:
-40°C~+105°C
-
Input Bias Current (Ib):
1pA
-
Input Offset Voltage (Vos):
5mV
-
Input Hysteresis Voltage (Vhys):
20mV
-
Common Mode Rejection Ratio (CMRR):
70dB
-
Package:
SC-88A
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
General Purpose
-
Voltage - Supply, Single/Dual (±):
0.85V ~ 6V
-
Voltage - Input Offset (Max):
5mV @ 6V
-
Current - Input Bias (Max):
1pA @ 6V
-
Current - Output (Typ):
-
-
Current - Quiescent (Max):
17µA
-
CMRR, PSRR (Typ):
70dB CMRR, 80dB PSRR
-
Propagation Delay (Max):
1.1µs
-
Hysteresis:
20mV
-
Package / Case:
5-TSSOP, SC-70-5, SOT-353
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-88A (SC-70-5/SOT-353)
-
Base Part Number:
NCS2202
-
detail:
Comparator General Purpose Open-Drain, Rail-to-Rail SC-88A (SC-70-5/SOT-353)
