NSVJ5908DSG5T1G دیتاشیت

NSVJ5908DSG5T1G

مشخصات دیتاشیت

نام دیتاشیت NSVJ5908DSG5T1G
حجم فایل 79.02 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت NSVJ5908DSG5T1G

دانلود دیتاشیت

سایر مستندات

NSVJ5908DSG5 6 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/JFETs
  • FET Type: 2PCSNChannel(Dual)
  • Datasheet: onsemi NSVJ5908DSG5T1G
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Input Capacitance (Ciss@Vds): 10.5pF@5V
  • Total Device Dissipation (Pd): 300mW
  • Drain Current (Idss@Vds,Vgs=0): 10mA@5V
  • Gate-Source Breakdown Voltage (V(BR)GSS): 15V
  • Gate-Source Cutoff Voltage (VGS(off)@ID): 300mV@100uA
  • Package: SC-88AFL
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Breakdown (V(BR)GSS): 15V
  • Drain to Source Voltage (Vdss): 15V
  • Current - Drain (Idss) @ Vds (Vgs=0): 10mA @ 5V
  • Current Drain (Id) - Max: 50mA
  • Voltage - Cutoff (VGS off) @ Id: 300mV @ 100µA
  • Input Capacitance (Ciss) (Max) @ Vds: 10.5pF @ 5V (Typ)
  • Power - Max: 300mW
  • Mounting Type: Surface Mount
  • Package / Case: 5-SMD, Flat Leads
  • Supplier Device Package: SC-88AFL/MCPH5
  • Base Part Number: NSVJ59
  • detail: JFET 2 N-Channel (Dual) 15V 50mA 300mW Surface Mount SC-88AFL/MCPH5
