دیتاشیت NCV4264-2CST33T3G
مشخصات دیتاشیت
| نام دیتاشیت | NCV4264-2C |
|---|---|
| حجم فایل | 225.712 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت NCV4264-2C |
NCV4264-2C Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCV4264-2CST33T3G
- Output Current: 100mA
- Output Voltage: 3.3V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 45V
- Operating Temperature: -40°C~+150°C
- Quiescent Current (Ground Current): 55uA
- Power Supply Rejection Ratio (PSRR): 67dB@(100Hz)
- Package: SOT-223
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 45V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): -
- Current - Output: 100mA
- Current - Quiescent (Iq): 55µA
- Current - Supply (Max): 70µA
- PSRR: 67dB (100Hz)
- Control Features: -
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: TO-261-4, TO-261AA
- Supplier Device Package: SOT-223 (TO-261)
- Base Part Number: NCV4264
- detail: Linear Voltage Regulator IC 1 Output 100mA SOT-223 (TO-261)
