دیتاشیت SZCM1213A-04SO

CM1213A-04SO

مشخصات دیتاشیت

نام دیتاشیت CM1213A-04SO
حجم فایل 430.88 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت CM1213A-04SO

CM1213A-04SO Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi SZCM1213A-04SO
  • Clamping Voltage@Ipp: 10V
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Breakdown Voltage (VBR): 6V
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: -
  • Reverse Stand-Off Voltage (Vrwm): 3.3V
  • Package: SC-74
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Steering (Rail to Rail)
  • Unidirectional Channels: 4
  • Voltage - Reverse Standoff (Typ): 3.3V
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: 10V (Typ)
  • Current - Peak Pulse (10/1000µs): 1A (8/20µs)
  • Power - Peak Pulse: -
  • Power Line Protection: Yes
  • Applications: Automotive
  • Capacitance @ Frequency: -
  • Mounting Type: Surface Mount
  • Package / Case: SC-74, SOT-457
  • Supplier Device Package: SC-74
  • Base Part Number: SZCM12
  • detail: 10V (Typ) Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount SC-74
