دیتاشیت NVD6495NLT4G-VF01
مشخصات دیتاشیت
| نام دیتاشیت | NVD6495NL |
|---|---|
| حجم فایل | 123.292 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت NVD6495NL |
NVD6495NL Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Operating Temperature: -55°C~+175°C@(Tj)
- Power Dissipation (Pd): 83W
- Total Gate Charge (Qg@Vgs): 35nC@10V
- Drain Source Voltage (Vdss): 100V
- Input Capacitance (Ciss@Vds): 1024pF@25V
- Continuous Drain Current (Id): 25A
- Gate Threshold Voltage (Vgs(th)@Id): 2V@250uA
- Drain Source On Resistance (RDS(on)@Vgs,Id): 50mΩ@10A,10V
- Package: TO-252
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 100V
- Current - Continuous Drain (Id) @ 25°C: 25A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 50mOhm @ 10A, 10V
- Vgs(th) (Max) @ Id: 2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 35nC @ 10V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 1.024nF @ 25V
- FET Feature: -
- Power Dissipation (Max): 83W (Tc)
- Mounting Type: Surface Mount
- Supplier Device Package: DPAK (SINGLE GAUGE)
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Base Part Number: NVD649
- detail: N-Channel 100V 25A (Tc) 83W (Tc) Surface Mount DPAK (SINGLE GAUGE)
