- دیتاشیت SBRS8320T3G
SBRS8320T3G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SBRS8320T3G |
|---|---|
| حجم فایل | 98.758 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت SBRS8320T3G |
دانلود دیتاشیت |
|---|
سایر مستندات
SMC Pkg Drawing 1 pages
MBRS320T3, MBRS330T3, MBRS340T3 4 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi SBRS8320T3G
- Diode Configuration: -
- Reverse Voltage (Vr): 20V
- Forward Voltage (Vf@If): 500mV@3A
- Reverse Leakage Current (Ir): 2mA@20V
- Average Rectified Current (Io): 4A
- Package: SMC(DO-214AB)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 20V
- Current - Average Rectified (Io): 3A
- Voltage - Forward (Vf) (Max) @ If: 500mV @ 3A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 2mA @ 20V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: DO-214AB, SMC
- Supplier Device Package: SMC
- Operating Temperature - Junction: -65°C ~ 150°C
- Base Part Number: SBRS83
- detail: Diode Schottky 20V 3A Surface Mount SMC
