FDMA3027PZ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDMA3027PZ	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: 2 P-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 30V
Current - Continuous Drain (Id) @ 25°C: 3.3A
Rds On (Max) @ Id, Vgs: 87mOhm @ 3.3A, 10V
Vgs(th) (Max) @ Id: 3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 10nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 435pF @ 15V
Power - Max: 700mW
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 6-VDFN Exposed Pad
Supplier Device Package: 6-MicroFET (2x2)
Base Part Number: FDMA30
detail: Mosfet Array 2 P-Channel (Dual) 30V 3.3A 700mW Surface Mount 6-MicroFET (2x2)
