دیتاشیت FDD86369-F085
مشخصات دیتاشیت
| نام دیتاشیت |
FDD86369
|
| حجم فایل |
1084.34
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi FDD86369-F085
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
150W
-
Total Gate Charge (Qg@Vgs):
54nC@10V
-
Drain Source Voltage (Vdss):
80V
-
Input Capacitance (Ciss@Vds):
2530pF@40V
-
Continuous Drain Current (Id):
90A
-
Gate Threshold Voltage (Vgs(th)@Id):
4V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
7.9mΩ@80A,10V
-
Package:
TO-252-3
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q101, PowerTrench®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
80V
-
Current - Continuous Drain (Id) @ 25°C:
90A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
7.9mOhm @ 80A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
54nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
2530pF @ 40V
-
FET Feature:
-
-
Power Dissipation (Max):
150W (Tj)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
D-PAK (TO-252)
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Base Part Number:
FDD863
-
detail:
N-Channel 80V 90A (Tc) 150W (Tj) Surface Mount D-PAK (TO-252)
