دیتاشیت DRV8829PWPR

DRV8829

مشخصات دیتاشیت

نام دیتاشیت DRV8829
حجم فایل 1599.621 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت DRV8829

DRV8829 Datasheet

مشخصات

  • Base Part Number: DRV8829
  • Motor Type - Stepper: Bipolar
  • Package / Case: 28-PowerTSSOP (0.173", 4.40mm Width)
  • Applications: General Purpose
  • Supplier Device Package: 28-HTSSOP
  • Current - Output: 3.5A
  • Voltage - Load: 8.2V ~ 45V
  • Interface: Parallel
  • Output Configuration: Half Bridge (2)
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Packaging: Cut Tape (CT)
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Step Resolution: -
  • Part Status: Active
  • Manufacturer: Texas Instruments
  • Series: -
  • Mounting Type: Surface Mount
  • Motor Type - AC, DC: Brushed DC
  • Voltage - Supply: 8.2V ~ 45V
  • Technology: Power MOSFET
  • detail: Bipolar Motor Driver Power MOSFET Parallel 28-HTSSOP
