دانلود دیتاشیت NVMFD6H852NL	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: Automotive, AEC-Q101
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss): 80V
Current - Continuous Drain (Id) @ 25°C: 7A (Ta), 25A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Rds On (Max) @ Id, Vgs: 25.5mOhm @ 10A, 10V
Vgs(th) (Max) @ Id: 2V @ 26µA
Gate Charge (Qg) (Max) @ Vgs: 10nC @ 10V
Vgs (Max): ±20V
Input Capacitance (Ciss) (Max) @ Vds: 521pF @ 40V
Power Dissipation (Max): 3.2W (Ta), 38W (Tc)
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: 8-DFN (5x6) Dual Flag (SO8FL-Dual)
Package / Case: 8-PowerTDFN
Base Part Number: NVMFD6
detail: N-Channel 80V 7A (Ta), 25A (Tc) 3.2W (Ta), 38W (Tc) Surface Mount 8-DFN (5x6) Dual Flag (SO8FL-Dual)
