دیتاشیت FDS8984-F085
مشخصات دیتاشیت
| نام دیتاشیت |
FDS8984-F085
|
| حجم فایل |
433.681
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
Automotive, AEC-Q101, PowerTrench®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
2 N-Channel (Dual)
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
7A
-
Rds On (Max) @ Id, Vgs:
23mOhm @ 7A, 10V
-
Vgs(th) (Max) @ Id:
2.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
13nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
635pF @ 15V
-
Power - Max:
1.6W
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
FDS89
-
detail:
Mosfet Array 2 N-Channel (Dual) 30V 7A 1.6W Surface Mount 8-SOIC
