دیتاشیت NCV4263-2CPD50R2G
مشخصات دیتاشیت
| نام دیتاشیت | NCV4263-2C |
|---|---|
| حجم فایل | 187.495 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت NCV4263-2C |
NCV4263-2C Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCV4263-2CPD50R2G
- Output Current: 200mA
- Output Voltage: 5V
- Dropout Voltage: 0.5V@(150mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 40V
- Operating Temperature: -40°C~+150°C
- Quiescent Current (Ground Current): 1.3mA
- Power Supply Rejection Ratio (PSRR): 80dB@(100Hz)
- Package: SOP-8-EP
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.5V @ 150mA
- Current - Output: 200mA
- Current - Quiescent (Iq): 1.3mA
- Current - Supply (Max): 23mA
- PSRR: 80dB (100Hz)
- Control Features: Enable, Reset, Watchdog
- Protection Features: Over Current, Over Temperature, Reverse Polarity
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
- Supplier Device Package: 8-SOIC-EP
- Base Part Number: NCV4263
- detail: Linear Voltage Regulator IC 1 Output 200mA 8-SOIC-EP
