دیتاشیت LB11961V-TLM-H

LB11961V

مشخصات دیتاشیت

نام دیتاشیت LB11961V
حجم فایل 72.505 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت LB11961V

LB11961V Datasheet

مشخصات

  • RoHS: true
  • Type: Brush DC Motor
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: onsemi LB11961V-TLM-H
  • Interface: Parallel
  • Output Current: 1A
  • Supply Voltage: 4.5V~16V
  • Operating Temperature: -30°C~+90°C@(Ta)
  • Package: SSOP-16-4.4mm
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (2)
  • Technology: Bipolar
  • Step Resolution: -
  • Applications: Fan Motor Driver
  • Current - Output: 1A
  • Voltage - Supply: 4.5V ~ 16V
  • Voltage - Load: 4.5V ~ 16V
  • Mounting Type: Surface Mount
  • Package / Case: 16-LSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 16-SSOP
  • Base Part Number: LB1196
  • detail: Motor Driver Bipolar Parallel 16-SSOP
