FDMS3602S دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDMS3602S	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Last Time Buy
FET Type: 2 N-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 25V
Current - Continuous Drain (Id) @ 25°C: 15A, 26A
Rds On (Max) @ Id, Vgs: 5.6mOhm @ 15A, 10V
Vgs(th) (Max) @ Id: 3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 27nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 1680pF @ 13V
Power - Max: 1W
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 8-PowerTDFN
Supplier Device Package: Power56
Base Part Number: FDMS36
detail: Mosfet Array 2 N-Channel (Dual) 25V 15A, 26A 1W Surface Mount Power56
