دیتاشیت HCPL2601SD
مشخصات دیتاشیت
| نام دیتاشیت | HCPL2601SD |
|---|---|
| حجم فایل | 70.903 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
HCPL2601SD |
دانلود دیتاشیت |
|---|
سایر مستندات
6N137, HCPL2601,11,30,31 15 pages
مشخصات فنی
- RoHS: true
- Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
- Data Rate: 10Mbit/s
- Datasheet: onsemi HCPL2601SD
- Input Type: DC
- Supply Voltage: 4.5V~5.5V
- Number of Channels: 1
- Operating Temperature: -40°C~+85°C
- Isolation Voltage(rms): 2500V
- Propagation Delay tpLH/tpHL: 75ns
- Common Mode Transient Immunity (CMTI): 5kV/us
- Package: SOP-8-2.54mm
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Inputs - Side 1/Side 2: 1/0
- Voltage - Isolation: 2500Vrms
- Common Mode Transient Immunity (Min): 5kV/µs
- Output Type: Open Collector
- Current - Output / Channel: 50mA
- Propagation Delay tpLH / tpHL (Max): 75ns, 75ns
- Rise / Fall Time (Typ): 50ns, 12ns
- Voltage - Forward (Vf) (Typ): 1.4V
- Current - DC Forward (If) (Max): 50mA
- Voltage - Supply: 4.5V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 8-SMD, Gull Wing
- Supplier Device Package: 8-SMD
- Base Part Number: HCPL26
- detail: Logic Output Optoisolator 10Mbps Open Collector 2500Vrms 1 Channel 5kV/µs CMTI 8-SMD
