HCPL0453R2 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت HCPL0453R2	دانلود دیتاشیت

RoHS: true
Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Phototransistor Output
Datasheet: onsemi HCPL0453R2
Output Current: 8mA
Forward Voltage: 1.45V
Number of Outputs: 1
Operating Temperature: -40°C~+85°C
Isolation Voltage(rms): 2500V
Package: SOP-8
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Number of Channels: 1
Voltage - Isolation: 2500Vrms
Current Transfer Ratio (Min): 19% @ 16mA
Current Transfer Ratio (Max): 50% @ 16mA
Turn On / Turn Off Time (Typ): 450ns, 300ns
Rise / Fall Time (Typ): -
Input Type: DC
Output Type: Transistor
Voltage - Output (Max): 20V
Current - Output / Channel: 8mA
Voltage - Forward (Vf) (Typ): 1.45V
Current - DC Forward (If) (Max): 25mA
Vce Saturation (Max): -
Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 8-SOIC
Base Part Number: HCPL04
detail: Optoisolator Transistor Output 2500Vrms 1 Channel 8-SOIC
