دیتاشیت CS5173EDR8G
مشخصات دیتاشیت
| نام دیتاشیت |
CS5171-74
|
| حجم فایل |
264.692
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
21
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType;Step-down type;Buck-boost type
-
Topology:
Step-down;Boost;Flyback;SEPIC
-
Datasheet:
onsemi CS5173EDR8G
-
Output Type:
Adjustable
-
Input Voltage:
2.7V~30V
-
Output Voltage:
1.28V~40V
-
Number of Outputs:
1
-
Switching Frequency:
560kHz
-
Output Current (Max):
1.5A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
SOP-8
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Output Configuration:
Positive or Negative
-
Voltage - Input (Min):
2.7V
-
Voltage - Input (Max):
30V
-
Voltage - Output (Min/Fixed):
1.28V
-
Voltage - Output (Max):
40V (Switch)
-
Current - Output:
1.5A (Switch)
-
Frequency - Switching:
560kHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
CS5173
-
detail:
Buck, Boost, Flyback, Forward Converter, SEPIC Switching Regulator IC Positive or Negative Adjustable 1.28V 1 Output 1.5A (Switch) 8-SOIC (0.154", 3.90mm Width)
