NRVBB60H100CTT4G دیتاشیت

NRVBB60H100CTT4G

مشخصات دیتاشیت

نام دیتاشیت NRVBB60H100CTT4G
حجم فایل 78.212 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت NRVBB60H100CTT4G

دانلود دیتاشیت

سایر مستندات

MBR(B)60H100CT, NRVBB60H100CT 7 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi NRVBB60H100CTT4G
  • Package: D2PAK-3
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 100V
  • Current - Average Rectified (Io) (per Diode): 30A
  • Voltage - Forward (Vf) (Max) @ If: 840mV @ 30A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 10µA @ 100V
  • Operating Temperature - Junction: 175°C (Max)
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Supplier Device Package: D2PAK-3
  • Base Part Number: NRVBB60
  • detail: Diode Array 1 Pair Common Cathode Schottky 100V 30A Surface Mount TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
