دیتاشیت AXM0F243-1-TX40
مشخصات دیتاشیت
| نام دیتاشیت |
AXM0F243
|
| حجم فایل |
462.009
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
52
|
مشخصات
-
RoHS:
true
-
Category:
Radio Frequency Chip/Antenna/RF Transceiver ICs
-
Data Rate:
1Mbps
-
Datasheet:
onsemi AXM0F243-1-TX40
-
Interface:
I2C,SPI,UART
-
Applications:
General-purpose ISM<1GHz
-
Frequency Range:
27MHz~1.05GHz
-
Receive Current:
6.5mA
-
Operating Voltage:
1.8V~3.6V
-
Operating Temperature:
-40°C~+85°C
-
Current Of Transmitting:
7.6mA
-
Package:
QFN-40-EP(5x7)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
TxRx + MCU
-
RF Family/Standard:
General ISM < 1GHz
-
Protocol:
Sigfox, Wireless M-Bus, Z-Wave®
-
Modulation:
4FSK, ASK, FSK, GFSK, GMSK, MSK, PSK
-
Frequency:
27MHz ~ 1.05GHz
-
Data Rate (Max):
1Mbps
-
Power - Output:
16dBm
-
Sensitivity:
-137dBm
-
Memory Size:
64kB Flash, 8kB SRAM
-
Serial Interfaces:
I²C, SPI, UART
-
GPIO:
20
-
Voltage - Supply:
1.8V ~ 3.6V
-
Current - Receiving:
6.5mA ~ 11mA
-
Current - Transmitting:
7.6 mA ~ 55 mA
-
Mounting Type:
Surface Mount
-
Package / Case:
40-VFQFN Exposed Pad
-
Supplier Device Package:
40-QFN (7x5)
-
detail:
IC RF TxRx + MCU General ISM < 1GHz Sigfox, Wireless M-Bus, Z-Wave® 27MHz ~ 1.05GHz 40-VFQFN Exposed Pad
