دیتاشیت FDMF2011
مشخصات دیتاشیت
| نام دیتاشیت |
FDMF2011
|
| حجم فایل |
782.896
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
31
|
مشخصات
-
RoHS:
true
-
Type:
MOSFET
-
Category:
Triode/MOS Tube/Transistor/Intelligent Power Modules (IPM)
-
Datasheet:
onsemi FDMF2011
-
Output Current:
20A
-
Output Voltage:
100V
-
Switching Frequency:
200kHz
-
Operating temperature:
-40°C~+125°C
-
Package:
PQFN-36-EP(6x7.5)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Half Bridge
-
Applications:
DC Motors, General Purpose
-
Interface:
PWM
-
Load Type:
Inductive, Capacitive
-
Technology:
Power MOSFET
-
Rds On (Typ):
7.3mOhm LS, 7.7mOhm HS
-
Current - Output / Channel:
20A
-
Current - Peak Output:
-
-
Voltage - Supply:
10V ~ 20V
-
Voltage - Load:
3V ~ 80V
-
Features:
Bootstrap Circuit
-
Fault Protection:
UVLO
-
Mounting Type:
Surface Mount
-
Package / Case:
36-SMD Module
-
Supplier Device Package:
36-PQFN (7.5x6)
-
Base Part Number:
FDMF20
-
detail:
Half Bridge Driver DC Motors, General Purpose Power MOSFET 36-PQFN (7.5x6)
