- دیتاشیت NCV5183DR2G
NCV5183DR2G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NCV5183DR2G |
|---|---|
| حجم فایل | 76.818 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت NCV5183DR2G |
دانلود دیتاشیت |
|---|
سایر مستندات
NCP5183, NCV5183 15 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Gate Drive ICs
- Datasheet: onsemi NCV5183DR2G
- Fall Time: 12ns
- Load Type: MOSFET
- Rise Time: 12ns
- Supply Voltage: 9V~18V
- Number of Drivers: 2
- Driven Configuration: Half Bridge
- Operating Temperature: -40°C~+125°C@(Tj)
- Peak Output Current(sink): 4.3A
- Peak Output Current(source): 4.3A
- Package: SOP-8
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Cut Tape (CT)
- Part Status: Active
- Channel Type: Independent
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 9V ~ 18V
- Logic Voltage - VIL, VIH: 1.2V, 2.5V
- Current - Peak Output (Source, Sink): 4.3A, 4.3A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 600V
- Rise / Fall Time (Typ): 12ns, 12ns
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: NCV5183
- detail: Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
