NCV5702DR2G دیتاشیت

NCV5702DR2G

مشخصات دیتاشیت

نام دیتاشیت NCV5702DR2G
حجم فایل 84.076 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

مشاهده دیتاشیت NCV5702DR2G

دانلود دیتاشیت

سایر مستندات

NCV5702 18 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: onsemi NCV5702DR2G
  • Fall Time: 7.9ns
  • Load Type: IGBT
  • Rise Time: 9.2ns
  • Supply Voltage: 20V
  • Number of Drivers: 1
  • Driven Configuration: Half Bridge
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Peak Output Current(sink): 6A
  • Peak Output Current(source): 4A
  • Package: SOP-16
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Channel Type: Synchronous
  • Gate Type: IGBT
  • Voltage - Supply: 20V
  • Logic Voltage - VIL, VIH: 0.75V, 4.3V
  • Current - Peak Output (Source, Sink): 1A, 1A
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): 9.2ns, 7.9ns
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SOIC
  • Base Part Number: NCV5702
  • detail: Half-Bridge Gate Driver IC Non-Inverting 16-SOIC
