دیتاشیت LV8702V-TLM-H

LV8702V

مشخصات دیتاشیت

نام دیتاشیت LV8702V
حجم فایل 499.97 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت LV8702V

LV8702V Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: Bipolar
  • Motor Type - AC, DC: -
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (4)
  • Interface: Parallel
  • Technology: BiCDMOS
  • Step Resolution: 1, 1/2, 1/4
  • Applications: General Purpose
  • Current - Output: 2.5A
  • Voltage - Supply: 0V ~ 5.5V
  • Voltage - Load: 9V ~ 32V
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 44-LSSOP (0.220", 5.60mm Width) Exposed Pad
  • Supplier Device Package: 44-SSOPJ
  • Base Part Number: LV870
  • detail: Bipolar Motor Driver BiCDMOS Parallel 44-SSOPJ
