دیتاشیت LV8713T-TLM-H

LV8713T

مشخصات دیتاشیت

نام دیتاشیت LV8713T
حجم فایل 249.246 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت LV8713T

LV8713T Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: onsemi LV8713T-TLM-H
  • Package: SSOP-24-4.4mm
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Motor Type - Stepper: Bipolar
  • Motor Type - AC, DC: -
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (4)
  • Interface: Parallel
  • Technology: Bi-CMOS
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 800mA
  • Voltage - Supply: 2.7V ~ 5.5V
  • Voltage - Load: 4V ~ 16V
  • Operating Temperature: -20°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 24-TFSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 24-TSSOP
  • Base Part Number: LV871
  • detail: Bipolar Motor Driver Bi-CMOS Parallel 24-TSSOP
