دیتاشیت NCH-RSL10-101S51-ACG
مشخصات دیتاشیت
| نام دیتاشیت | RSL10 SIP Datasheet |
|---|---|
| حجم فایل | 1505.295 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت RSL10 SIP Datasheet |
RSL10 SIP Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 4Mbps
- Datasheet: onsemi NCH-RSL10-101S51-ACG
- Interface: PCM,SPI,UART
- Applications: Bluetooth
- Frequency Range: 2.36GHz~2.5GHz
- Receive Current: 3mA
- Operating Voltage: 1.18V~3.3V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 4.6mA
- Package: SIP-51
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: TxRx + MCU
- RF Family/Standard: Bluetooth
- Protocol: Bluetooth v5.0
- Modulation: 4-FSK, FSK, GFSK, MSK, O-QPSK
- Frequency: 2.36GHz ~ 2.5GHz
- Data Rate (Max): 4Mbps
- Power - Output: 6dBm
- Sensitivity: -96dBm
- Memory Size: 384kB Flash, 76kB SRAM, 88kB SRAM
- Serial Interfaces: PCM, SPI, UART
- Voltage - Supply: 1.18V ~ 3.3V
- Current - Receiving: 3mA ~ 6.2mA
- Current - Transmitting: 4.6mA ~ 8.9mA
- Mounting Type: Surface Mount
- Package / Case: 51-SMD Module
- Supplier Device Package: 51-SIP (8x6)
- Base Part Number: RSL1
- detail: IC RF TxRx + MCU Bluetooth Bluetooth v5.0 2.36GHz ~ 2.5GHz 51-SMD Module
