FSGM0565RWDTU دیتاشیت

FSGM0565RWDTU

مشخصات دیتاشیت

نام دیتاشیت FSGM0565RWDTU
حجم فایل 81.115 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

مشاهده دیتاشیت FSGM0565RWDTU

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Flyback
  • Datasheet: onsemi FSGM0565RWDTU
  • Duty Cycle: 70%
  • Supply Voltage: 7.5V~26V
  • Output Isolation: Isolation
  • Breakdown Voltage: 650V
  • Switching Frequency: 66kHz
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Package: TO-220F
  • Manufacturer: onsemi
  • Series: FPS™
  • Packaging: Tube
  • Part Status: Active
  • Internal Switch(s): Yes
  • Voltage - Breakdown: 650V
  • Voltage - Start Up: 12V
  • Voltage - Supply (Vcc/Vdd): 7.5V ~ 26V
  • Frequency - Switching: 66kHz
  • Power (Watts): 80W
  • Fault Protection: Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
  • Control Features: -
  • Package / Case: TO-220-6 Full Pack, Formed Leads
  • Supplier Device Package: TO-220F-6L (W-Forming)
  • Mounting Type: Surface Mount
  • Base Part Number: FSGM05
  • detail: Converter Offline Flyback Topology 66kHz TO-220F-6L (W-Forming)
