MBR2515LG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MBR2515LG
|
|
حجم فایل
|
59.22
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi MBR2515LG
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
15V
-
Forward Voltage (Vf@If):
0.41V@25A
-
Reverse Leakage Current (Ir):
1mA@15V
-
Average Rectified Current (Io):
25A
-
Package:
TO-220-2
-
Manufacturer:
onsemi
-
Series:
SWITCHMODE™
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
15V
-
Current - Average Rectified (Io):
25A
-
Voltage - Forward (Vf) (Max) @ If:
450mV @ 25A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
15mA @ 15V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-2
-
Supplier Device Package:
TO-220-2
-
Operating Temperature - Junction:
-65°C ~ 125°C
-
Base Part Number:
MBR2515
-
detail:
Diode Schottky 15V 25A Through Hole TO-220-2
