MBRB3030CTLG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MBRB3030CTLG	دانلود دیتاشیت

RoHS: true
Category: Diodes/Switching Diode
Datasheet: onsemi MBRB3030CTLG
Power Dissipation: -
Diode Configuration: Dual Common Cathode
Reverse Voltage (Vr): 30V
Operating Temperature: -55°C~+125°C@(Tj)
Forward Voltage (Vf@If): 510mV@30A
Reverse Leakage Current: 200uA@30V
Reverse Recovery Time (trr): -
Average Rectified Current (Io): 15A
Package: D2PAK
Manufacturer: onsemi
Series: SWITCHMODE™
Packaging: Tube
Part Status: Obsolete
Diode Type: Schottky
Voltage - DC Reverse (Vr) (Max): 30V
Current - Average Rectified (Io) (per Diode): 15A
Voltage - Forward (Vf) (Max) @ If: 440mV @ 15A
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr: 2mA @ 30V
Operating Temperature - Junction: -55°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package: D2PAK-3
Base Part Number: MBRB3030
detail: Diode Array 1 Pair Common Cathode Schottky 30V 15A Surface Mount TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
