MJF47G دیتاشیت

MJF47G

مشخصات دیتاشیت

نام دیتاشیت MJF47G
حجم فایل 97.473 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

مشاهده دیتاشیت MJF47G

دانلود دیتاشیت

سایر مستندات

MJF47 6 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
  • Datasheet: onsemi MJF47G
  • Transistor Type: NPN
  • Operating Temperature: -65°C~+150°C@(Tj)
  • Collector Current (Ic): 1A
  • Power Dissipation (Pd): 2W
  • Transition Frequency (fT): 10MHz
  • DC Current Gain (hFE@Ic,Vce): 30@300mA,10V
  • Collector Cut-Off Current (Icbo): 200uA
  • Collector-Emitter Breakdown Voltage (Vceo): 250V
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 1V@1A,200mA
  • Package: TO-220FPAB-3
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Current - Collector (Ic) (Max): 1A
  • Voltage - Collector Emitter Breakdown (Max): 250V
  • Vce Saturation (Max) @ Ib, Ic: 1V @ 200mA, 1A
  • Current - Collector Cutoff (Max): 200µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 300mA, 10V
  • Power - Max: 2W
  • Frequency - Transition: 10MHz
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3 Full Pack
  • Supplier Device Package: TO-220FP
  • Base Part Number: MJF47
  • detail: Bipolar (BJT) Transistor NPN 250V 1A 10MHz 2W Through Hole TO-220FP
